Model: HX-1064
Delivery time: 25-30 working days
Payment method: bank transfer or letter of credit
Warranty period: 2 years
Advantages: Automation, easy to use
Corrugated iron sheet making machine-1064
The corrugated roller forming machine comes in a variety of models. This type of roof tile is widely used in various industrial plants, civil buildings and ancillary facilities construction, and has significant advantages such as exquisite appearance and long service life.
|
No.
|
Corrugated iron sheet making machine-1064
|
|
|
1
|
Suitable to process
|
Color alu-zinc steel coil
|
|
2
|
Roller
|
13 Rows
|
|
3
|
Dimensions
|
6.75*1.6*1.8m
|
|
4
|
Motor Power
|
4Kw
|
|
5
|
Pump Station Motor
|
4Kw.Lichao Brand
|
|
6
|
Thickness of the plate
|
0.3-0.8mm
|
|
7
|
Productivity
|
10-15m/min
|
|
8
|
Material of the cutting blade
|
Cr12,Quenched treatment 58℃-60℃
|
|
9
|
Diameter of the roller
|
Φ70mm
|
|
10
|
Weight
|
About 4300kgs
|
|
11
|
Main structure of the machine
|
350H beams
|
|
12
|
Processing precision
|
Within 1.0mm
|
|
13
|
Side panel of machine
|
16mm
|
|
14
|
Chain Wheel and Cycle Chain
|
1 Inch
|
|
15
|
Voltage
|
380V 50Hz 3phases or as customer’s need
|
|
16
|
Control system
|
PLC control (Delta)
|
|
17
|
Frequency system
|
Delta
|
|
18
|
Drive mode
|
Motor driver
|
|
19
|
Touch screen
|
Delta
|
|
20
|
Rolling materials
|
45# forging steel with chromium plate
|
|
21
|
Length Tolerance
|
±2mm
|
Detail
Main parameters of the corrugated roller forming machine 1064
Advantages
Q: Why choose us?
1. 28 + Years of Expertise since 1996, Leading Quality Roof Roll Forming Industry.
2. Design and Making High-Quality Roll Forming Machines with Customization,Tailor-Made Solutions.
3. Competitive Pricing & Superior Performance,Cost-Effective Solutions.
4. Service Customers more 150+ Countries – Your Best Roll Forming Machine Partner.
Q:What service can you provide before order?
About the pre-sale service, We provide professional solutions according your demands, such as design, technical parameter, delivery flow etc. at the same time, we can supply invitation letter for your visit our factory and know more our factory.
Q:What's the machine advantage?
1. Easy to operate: The double layer roll forming machine adopts a humanized operating interface and intelligent control system, making the operation easier and faster, and reducing the labor intensity of workers.
2. Easy maintenance: The double layer roll forming machine structure design is reasonable, easy to maintain and extends the service life of the equipment.
3. High performance: Although the double layer roll forming machine is superior to similar products in terms of performance and quality, its price is relatively reasonable with high performance.
