Develivery time:20- 25days
Model:HX-5-ton hydraulic decoiler for sale
Payment:30% T/T deposit,70% balance before shipping
Voltage:380V 50HZ 3Phase or based on customer’s need
Warranty :2 years for machinery warranty|
The 5-ton hydraulic uncoiler is a medium and small-sized hydraulic-driven metal coil feeding equipment, specially designed for materials such as steel coils, aluminum coils, and color-coated plates. With a maximum load capacity of no more than 5 tons, it can achieve automated uncoiling operations
Detail
|
HX-5Tons decoiler
|
||
|
1
|
Size
|
2.7*1.6*1.9meters
|
|
2
|
Weight
|
3.2Tons (Include loading trolley)
|
|
3
|
Main axis
|
194mm
|
|
4
|
Motor Power
|
4Kw
PM250 Steel reducer,Speed ratio 40:17 |
|
5
|
Pump Station Motor
|
4Kw ,Brand Lichao,Shanghai
|
|
6
|
Frequency Inverter
|
5.5Kw,Sanjing
|
|
7
|
Cylinder type
|
100 Rotating cylinder
|
|
8
|
Bottom shelf
|
300-350 H Beams
|
|
9
|
The whole box iron plate
|
14mm
|
|
10
|
Max put weight
|
5Tons
|
|
11
|
Max coil width
|
1000mm(or according to your need)
|
|
12
|
Coil diameter
|
470-530mm or customer’s need
|
|
13
|
Control Box
|
Delta ,Taiwan
|
|
14
|
Power
|
380V 50HZ 3Phase or customer’s need
|
Quality assurance:
12-month warranty for the whole machine
Technical support:
7×24-hour emergency response:
✓ Telephone technical support
✓ Email remote diagnosis
✓ Video conference guidance
Maintenance service:
Free fault repair within two years
Lifetime paid maintenance service
