1035 double sheet roll forming machine
The 1035 double sheet roll forming machine is designed to produce double-layer roofing sheets with high precision and consistent quality. It minimizes material waste with an efficient cutting and forming process. The dual-sheet design increases production efficiency and reduces energy consumption. Equipped with an automated system, the machine ensures stable output with minimal human intervention. Built for durability and easy maintenance, it is perfect for large-scale roofing projects, offering cost-effective and reliable solutions for industrial and commercial uses.
1035 sheet roll forming machine
Detail
1035 sheet roll forming machine
|
No.
|
1035 sheet roll forming machine
|
|
|
1
|
Suitable to process
|
Color alu-zinc steel coil
|
|
2
|
Roller
|
AG Panel : 12 Rows
R panel/Pbr Panel :15Rows
|
|
3
|
Dimensions
|
6.75*1.6*1.8m
|
|
4
|
Motor Power
|
4Kw
|
|
5
|
Pump Station Motor
|
4Kw.Lichao Brand
|
|
6
|
Thickness of the plate
|
0.3-0.8mm
|
|
7
|
Productivity
|
10-15m/min
|
|
8
|
Material of the cutting blade
|
Cr12,Quenched treatment 58℃-60℃
|
|
9
|
Diameter of the roller
|
Φ70mm
|
|
10
|
Weight
|
About 4300kgs
|
|
11
|
Main structure of the machine
|
350H beams
|
|
12
|
Processing precision
|
Within 1.0mm
|
|
13
|
Side panel of machine
|
16mm
|
|
14
|
Chain Wheel and Cycle Chain
|
1 Inch
|
|
15
|
Voltage
|
380V 50Hz 3phases or as customer’s need
|
|
16
|
Control system
|
PLC control (Delta)
|
|
17
|
Frequency system
|
Delta
|
|
18
|
Drive mode
|
Motor driver
|
|
19
|
Touch screen
|
Delta
|
|
20
|
Rolling materials
|
45# forging steel with chromium plate
|
|
21
|
Length Tolerance
|
±2mm
|
